What's going on everybody and welcome to a Technician's Tuesday where every
0:04
Tuesday I will be bringing you along with me through a normal day as a marine mechanic. I'll be giving out some helpful hints, tips, and outboard service
0:12
tricks along with showing you a sneak peek into future videos of repowers
0:16
rewires, and restoration projects. So hit that subscribe button and without further
0:22
ado let's get into this week's video. This week's Tuesday was pretty calm
0:27
Started off the morning by finishing up installing all the controls on the
0:31
upper station for the venture, which is a project I think you guys are really
0:34
gonna love but I'll introduce that at the end of the day. I installed the
0:38
digital control box, the GPS, and the digital gauges, which we put on a slanted
0:43
bezel so you could read them through the steering wheel. It came out really smooth. Then added the steering wheel and two cup holders. Then we had a 37-foot Boston
0:52
Whaler with triple 300 Mercury Verados come in with no power steering. First
0:56
thing you want to do when looking at these steering systems is make sure that
1:00
it is not the sensing circuit coming from the engines. We activate that by
1:04
using a tool to bypass that and send the turn on signal straight to the pump. If
1:09
that doesn't turn it on we then want to make sure that the pump is getting
1:13
voltage. On these power steering systems they incorporate a switch for the pump
1:17
to pull power from the strongest battery. Make sure there is power at the output
1:21
side of the switch. Then check the large fuse that is in line. And last but not
1:26
least cut the wires at the crimped portion of the wire at the pump and do a
1:30
load test. After performing all these tests and nothing happening it's time to
1:34
replace the pump. When working on a boat and dealing with tons of wires never be
1:38
afraid to get in and cut out all the zip ties. It will make the job ten times
1:42
easier. Remember if something is in the way then move it. We'll be putting new
1:46
zip ties on when we've completed the job anyway. For this we simply remove the old
1:51
pump and put in a new one. Liquid electric tape is nice to put onto the
1:54
studs and then before putting everything back together we will test out the new pump and purge the air out of the system. In order to do this all we
2:02
need to do is just turn on the engine and pour the fluid in until it reaches
2:06
about one inch or so from the top of the reservoir. Then turn the engine back and
2:10
forth a couple times to get all the air to come out. And that's it we are done
2:14
This boat also had a shifting issue on the port engine but after testing the
2:18
shift actuator and checking the lower unit oil we could not duplicate the
2:22
problem so the client came and picked up his boat happy to be back out on the
2:26
water. With about two hours left in the day I took some measurements from the
2:30
upper station of the venture and built a starboard bracket to bolt the mercury
2:34
command modules and junction boxes to and a power block to connect the GPS to
2:38
as well. It will also be used to screw zip tie holders to in order to tie down
2:43
all of the harnesses to give what is called tension relief to any electrical
2:47
plug. Manufacturers want to have some sort of support for the wire within six
2:51
inches of the plug to relieve the stress and constant pulling of the wire when
2:55
the boat is going through rougher water. And this ends our day here on Tuesday
2:59
but I didn't forget here's the current project that is in the works. This is a
3:03
1999 34 venture named Desperado. It originally had Yamaha 250 horsepower OX66's on it then got repowered with two Yamaha 250 four-stroke engines. Still
3:15
using the Yamaha 6x1 boxes eventually became such a problem that you could
3:20
barely take the boat out without having a serious issue. So this boat is getting
3:24
rewired and a pair of mercury 300 horsepower Verados put on it. Lots of
3:28
upgrades too from the hatch latches and gas shocks to the autopilot system this
3:33
boat is going to be super sweet when we get done with it. And we'll be making a
3:37
video of that entire process as well so we hope you'll get subscribed to the
3:40
channel and get that bell on so when the video drops you will know it. Thanks for
3:45
joining us on this Technicians Tuesday and we'll see you next week
